Spur Gearboxes

The standard gear range of 3~250 can be extended by adding a gear advance to the range of 3~2500.

Specifications - parameters

Type	Gear Ratio	Max. output torque (Nm)	For AC motor with power (W)	For DC motor with power (W)
K6G□B(C)	3 ~ 2500	3	6	6
K7G□B(C)	3 ~ 2500	5	15	15
K8G□B(C)	3 ~ 2500	8	15	25 ~ 40
K9G□B(C)	3 ~ 2000	10	40	60 ~ 200
K9P□B K9P□BF	3 ~ 2000	20	40 ~ 180	60 ~ 200
K9P□BU K9P□BUF	3 ~ 2000	30	40 ~ 180	60 ~ 200
K10H□B	3 ~ 2000	40	200	-

□: shaft types (S - solid with groove, G - pinion)

The output speeds and torques of the motors in combination with the spur gearbox can be found in the PDF catalogues in the table.

Downloads

Download catalog

K6G□B(C).pdf K7G□B(C).pdf K8G□B(C).pdf K9G□B(C).pdf K9P□B.pdf K10H□B.pdf

3D models

Celni prevodovky K6G□B(C).zip Celni prevodovky K7G□B(C).zip Celni prevodovky K8G□B(C).zip Celni prevodovky K9G□B(C).zip Celni prevodovky K9P□B.zip Celni prevodovky K9P□BF.zip Celni prevodovky K9P□BU.zip Celni prevodovky K9P□BUF.zip
